iND87400A/L is a highly integrated motor control chip that combines an MCU with a LIN PHY, LDO, operational amplifier, and motor control PWM module.
Product Highlights:
Highly integrated, achieving the smallest package size in the industry.
Rich in application functions and IO resources, with easy development features.
Supports various types of motor drives such as BDC/Stepper/BLDC and relay control.
Parameter Name | Parameter Value |
CPU | Arm Cortex M0 |
Frequency max | 16MHz | 45MHz |
Flash | 48KB |
EEPROM | Emulated by Flash |
SRAM | 16KB | 8KB |
Power Supply | 6 – 18V |
ADC | 12-bits |
CSA | 1 |
Timer | 16-bit * 5 |
Advanced PWM | 4 Pairs |
High-current Drivers | – |
Communication | UART *1 |
LIN Transceiver | Integrated |
Temperature Tj | -40 – +150℃ |
Package | QFN24 4*4mm |
