Automotive Lighting controller

IND83209

  • ARM cortex-M0 core @16MHz
  • 64KB FLASH + 16KB SRAM
  • Support maximum 60mA high voltage constant current source RGB LED driver, with 100uA step current size
  • 3 * 16 bit PWM
  • Integrated internal LDO
  • LED PN junction voltage detect circuit
  • Hardware over-voltage and over-temperature protection
  • 2 * LIN V2.2 controller and transceiver
  • LIN auto addressing and LIN address extension
  • in VW group approval list,J2602 passed
  • 6 * General Purpose I/O
  • Internal temperature sensor
  • 10-bit SAR ADC
  • QFN 4×4 – 20pins, 0.5mm pitch, ground Pad package
  • AECQ-100
  • Primary Application: Interior Light

IND83211

  • ARM cortex-M0 core @16MHz
  • 64KB FLASH + 16KB SRAMiND83211
  • Buck converter and LDO integrated
  • 24 * 45mA high voltage constant current source RGB LED driver – supports up 24 RGB LEDs using time multiplexing
  • 24 * 16bit PWM with independent pre-scaler
  • 2 * LIN V2.2 controller and transceiver
  • LIN auto addressing and LIN address extension
  • in VW group approve list, J2602 passed
  • LED PN junction voltage detect circuit
  • UART and SPI
  • 9 * General Purpose I/O
  • Internal temperature sensor
  • 28ch 10-bit SAR ADC
  • QFN 6×6 – 48 pin, 0.4mm pitch, ground pad package
  • AEC-Q100 certified – Q4 2021
  • Primary Application: Interior Light , Starlight,Tail Light

IND83080/83081

  • Full automotive qualification AEC-Q100 Grade1
  • 12 MOSFET grouped to four blocks, both in series or in parallel supported
  • 170mohm Rdson
  • Support both BAT12V direct supply and external 5V
  • 12bit Direct PWM with independent control
  • Elins protocol based on UART up to 1Mbps with CRC, optional external CAN physical layer to improve robust and EMC
  • Support up to 32 matrix IC in one bus, Sync by protocol
  • High accurate oscillator integrated with EMC improvement
  • Internal MTP up to 2Kbit for system configuration and limp home configuration
  • Programmable Limp home mode in case of communication failure, internal watch dog to monitor communication statues
  • On chip temperature monitor for IC temperature monitor
  • 11 bit ADC to monitor Bin,and NTC,BAT, charge pump statues
  • Slew rate and phase shift control to avoid current spike
  • Single LED short /open detection
  • Standalone mode
  • Primary Application:Exterior lighting, Dynamic lighting,ADB,DRL/Pl
